Reference design for humidity and temperature sensors

26 May 2021 Design Automation

The SHT4x Smart Gadget is a simple reference design circuit board which demonstrates the performance and ease of use of Sensirion’s SHT4x humidity and temperature sensors. It is equipped with a liquid crystal display (LCD) showing humidity and temperature information and also features a Bluetooth Low Energy (BLE) module allowing it to communicate with BLE-capable devices like smartphones.

The board features:

• SHT40 humidity and temperature sensor.

• LCD display for humidity, temperature and dew point in Celsius and Fahrenheit.

• Bluetooth Low Energy (BLE) connectivity to iOS and Android smartphones.

• iOS and Android apps available.

• Data logging capabilities.

• Additional design resources available.
