Touchscreen controller family gets additional security features

31 May 2024 Opto-Electronics

Typical touch-enabled human machine interface (HMI) and radio frequency identification (RFID) combination-based payment systems are vulnerable to hacking attacks via malicious software updates or man-in-the-middle attacks when a user enters their personal identification number (PIN) on the touchscreen. Physical mesh barriers and sensors are often used around these integrated circuits (ICs) for protection from hacking. Constant reflashing of software and device resets are used to help safeguard software integrity.

The MXT2952TD 2.0 family is designed to encrypt touch data and cryptographically authenticate software updates to minimise risk and meet PCI certification compliance standards. When the RFID reader IC and the touchscreen controller are on different printed circuit boards, it is especially difficult and expensive to build physical barriers for hack protection. Embedded firmware on the MXT2952TD 2.0 provides a more easily implemented solution to allow EV charger manufacturers to both remain compliant with security regulations, and avoid the cost of adding a second, expensive touchscreen payment module to the charger.

The outdoor nature of EV charger HMIs demand they withstand harsh weather conditions, function accurately in the presence of moisture, and are resistant to vandalism. MXT2952TD 2.0 touch controller-based touchscreens remain effective when designed with IK10 standard

6 mm-thick glass, anti-reflective, anti-glare and anti-fingerprint coatings, and IR filter/UV filter layers. Microchip’s proprietary differential touch sensing delivers exceptional noise immunity for superior touch performance, even when used with thick gloves.

“The maXTouch 2952TD 2.0 family provides EV charger designers with a cost-effective, secure design architecture for implementing credit card payments with PIN entry on their touchscreens,” said Patrick Johnson, senior corporate vice present overseeing Microchip’s human machine interface division. “Combined with the rugged, outdoor HMI touchscreen technology that Microchip’s maXTouch portfolio is known for, the new addition to the 2952TD family of touchscreen controllers offers our customers secure designs and the exceptional touch performance necessary for outdoor applications.”
