Antenova has launched Inpai, a new SMD cellular antenna designed for NB-IoT and CATM on 4G/LTE networks. The Inpai antenna, with a slightly smaller footprint than the popular Lucida antenna, operates on all LTE and mobile bands.
The new addition provides exceptional performance in a compact design, measuring 35 x 8 x 3,3 mm with a clearance of 35 x 13 mm. Optimal performance requires the antenna to be positioned along the short end of the PCB measuring 100 x 40 mm. This makes the board 25 mm shorter than the Lucida antenna for smaller device designs.
The Inpai antenna performs efficiently on all cellular networks with multi-band efficiency being impressive in all bands after PTCRB certification testing delivering positive results. Results returned 48,8% at frequencies from 698 – 960 MHz, 61,5% from 1710 – 2170 MHz, 68,7% from 2300 – 2400 MHz, and 55% from 2500 – 2690 MHz.
