All-silicon CMOS oscillator replaces xtals

6 October 2004 Electronics Technology

Micro Oscillator has designed and patented a 32 kHz all-silicon CMOS-based clock oscillator that can replace 32 kHz crystals in microprocessor and microcontroller-based systems for very robust operation. The MOI-32 temperature compensated oscillator operates at 0,01%, or 100 ppm, total frequency accuracy over the temperature (0 to 70°C) and voltage range without using quartz crystals or other external components. The MOI-32 has a main frequency of 32,768 kHz - other frequencies can be realised. The MOI-32 will also operate over the industrial range of -40 to 85°C with a total tolerance of 0,025%, or 250 ppm. The oscillator operates at 3 or 1,8 V, consuming a mere 50 μA.

www.micro-oscillator.com.
